Engineering Drawing & CAD Standards is a book written by C. Bales and M. Vlamakis from Moraine Valley Community College. It is used to teach the standards and practices of creating engineering drawings and working with computer-aided design (CAD) software.

FAQ

Q: What is the purpose of engineering drawing?
A: The purpose of engineering drawing is to communicate complex ideas and designs in a clear and detailed manner.

Q: What are CAD standards?
A: CAD standards are guidelines and specifications that dictate how drawings and models should be created and presented using computer-aided design (CAD) software.

Q: Why are CAD standards important?
A: CAD standards ensure consistency and compatibility in design documentation, making it easier for different engineers and teams to collaborate and work with the same CAD files.

Q: What are some common CAD standards?
A: Common CAD standards include file naming conventions, layering standards, dimensioning rules, and drawing sheet layouts.

Q: What is the role of Moraine Valley Community College in engineering drawing and CAD standards?
A: Moraine Valley Community College offers courses and programs that teach engineering drawing and CAD standards, providing students with the necessary skills and knowledge for a career in engineering and design.
